Control RK MultiControl II duo/RK MultiControl II quadro
8.5.7.3
'SERVICE DRIVE' menu
Advanced password
The menu is only displayed if the advanced password has
been set
The advanced password is available on request from
RK Rose+Krieger GmbH.
Selecting the 'SERVICE DRIVE' menu
The function allows you to move individual or multiple drives
even in the event of an error for troubleshooting purposes.
◼ The main menu for the hand switch is displayed
Prerequisite:
Selecting a menu
Select the menu via 'Control' → 'Service' → 'SERVICE DRIVE'
1.
⇨ The 'SERVICE DRIVE' menu (Figure 126) is displayed.
(Figure 125).
⮱
page 232.
In the 'SERVICE DRIVE' menu (Figure 126) one or
multiple drives ( 'M1' - 'M4' ) can be selected and
their positions can be displayed.
'PWM' (pulse width modulation) is used to set the
speed of the selected drive and the selected drive
is moved using 'run'.
⮱
8.3 on page 215.
265
