Control RK MultiControl II duo/RK MultiControl II quadro
Setting the absolute value target position
2.
Press the
3.
Set the absolute target position (Figure 43).
Driving to an absolute target position
⇨ The drive stops automatically when the target position is rea-
4.
Press and hold the
ched.
8.4.1.1.3 'Relative air positioning' menu
This function activates relative positioning.
It is used for gradual positioning to a defined value
(e.g. 20% or 20 mm) in relation to the current position
of the drive.
◼ The main menu for the hand switch is displayed.
Prerequisite:
button ( ).
Figure 42 - 'Absolute positioning' mode
Figure 43 - Entering a value
button (
).
⮱
8.3 on page 215
219
