8.5.5
Control RK MultiControl II duo/RK MultiControl II quadro
'Sync-BUS settings' menu
If a stop function (safety edge or stop input switch) is
required for a sync BUS system, the stop function must be
connected to the master control unit.
The collision detection (SPP) function can be activated,
configured and used on every control unit in the sync BUS
system.
8.5.5.1 'Start search for slave controls' menu
This function searches for connected control units
⮱
(
This function cannot be activated when drive group
management is activated.
◼ The synchronisation bus is connected
Prerequisites:
◼ The hand switch on the master control unit is connected
◼ The main menu for the hand switch is displayed
Selecting a menu
Call up the menu via 'Control' → 'Sync-BUS settings' → 'Start search for
1.
⇨ All the connected control units are reset.
slave controls' (Figure 113).
6.4.5 on page 198) and activates the bus connection.
⮱
page 198
⮱
⮱
8.3 on page 215
page 198
