4.5.5
Pin
1
2
3
4
5
6
7
8
184
Drive slot - RK MultiControl II duo/quadro
Figure 15 - Drive slot contacts
◼ Activation of the drive (output)
Function Description
◼ 0 - 28.5 VDC
Motor +
◼ Signal contact input
◼ Contact type: NC
Bottom limit
◼ If the limit switch is not actuated, there is +12 VDC
switch
◼ In the final position the connected limit switch contact is
◼ Hall sensor signal inputs
+ 12 VDC Supply to Hall sensors and limit switches (output)
◼ Hall sensor output type: open collector
Hall sensor A
◼ Signal contact input
Hall sensor B
◼ Contact type: NC
Top limit switch
◼ If the limit switch is not actuated, there is +12 VDC
◼ In the final position the connected limit switch contact is
◼ Activation of the drive (output)
GND Supply to Hall sensors (output)
◼ 0 - 28.5 VDC
Motor -
open
open
Control RK MultiControl II duo/RK MultiControl II quadro
