Product description

This section provides an overview of the most im-
portant devices and components required for tes-
ting and repairing the AdBlue supply module, type
Denoxtronic 2.2. Detailed instructions on the use and
handling can be found in the separate ESI[tronic]
repair instructions Denoxtronic 2.2.
3.1

Intended use

The devices and components of the parts sets
0 986 610 541 and 0 986 610 561 are intended ex-
clusively for testing and repairing the AdBlue supply
modules of the type Denoxtronic 2.2.
!
Nonobservance can lead to accidents and damage!
3.1.1 Extension set 0 986 610 541
The tester set Denoxtronic 1.1 (0 986 610 551), in
conjunction with the extension set Denoxtronic 2.1
(0 986 610 581), can be expanded to the scope of deli-
very of the tester set Denoxtronic 2.2 (0 986 610 561)
by means of the extension set 0 986 610 541.
The tester set Denoxtronic 2.1 (0 986 610 571) can
be expanded to the scope of delivery of the tester
set Denoxtronic 2.2 (0 986 610 561) by means of the

extension set 0 986 610 541.

Robert Bosch GmbH
Product description | Denoxtronic 2.2 | 23 |
3.2

Scope of delivery

i
The components marked with an asterisk (*) are
comprised in the scope of delivery of the extension
set 0 986 610 541.
Designation
Hose set*
Base plate*
Mounting frame*
Mounting mandrel*
Pressure gauge*
Holder for pressure gauge*
Hand pump*
Test control device (12 V)*
Test control device (24 V)*
Tester set*
Socket housing (12 V)*
Socket housing (24 V)*
Locking piece
Test dosing module*
Beaker set
Drain valve parts set*
Clamping support
Rod
Scale
Weight
Clamp*
Extraction device*
Warning sign*
Warning sign*
Gas manifold
Supply line
Supply line
Sealing device
Operating instructions*
3.3

Special accessories

For required special accessories, see section 4.
