Parameter List
PNU OP1S parameter name
Description
*
: Conf.
Par.
5.5

Hardware configuration

P090 Board Position 2
PCB in position 2 (right) of the electronic box
*
0 = No optional PCBs
1 = CB Communication Board
2 = TB Technology Board
3 = SCB Serial Communication Board
Description for Setting:
Only the following combinations of PCBs and positions are admitted:
Position 3(P091)
-
-
-
SCB
CB
SCB
CB
PNU=5AHex; Type=O2; Scaling: 1Hex
P091 Board Position 3
PCB in position 3 (center) of the electronic box
*
Description see P090(PCB position 2)
PNU=5BHex; Type=O2; Scaling: 1Hex
5-10
ENGLISH
Position 2(P090)
CB
TB
SCB
CB
TB
TB
SCB
∧ 1
=
∧ 1
=
Value range Display
[phys. unit] Indices
Selection text Factory-
setting
0 to 3 -
0
none
CB
TB
SCB
0 to 3 -
0
Text as for P090
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
09.02
See
Modify
(access /
status)
3/ HBR
3/ H
3/ HBR
3/ H
