Siemens SIMOVERT Master Drives 6SE70 Betriebsanleitung Seite 372

Parameter List
PNU OP1S parameter name
Description
*
: Conf.
Par.
P603 Trg Bit Fault
Destination of the status bit 'Fault' (status word 1, bit 3)
*
Note:
For issuing the fault message via a terminal the active status (bit has H-
level) is inverted (broken wire proof).
Parameter values, indices: as P600
PNU=25BHex; Type=L2; Scaling: 1Hex
P604 Trg Bit No OFF2
Destination of the status bit 'No OFF2 command' (status word 1, bit 4)
*
Parameter values, indices: as P600
PNU=25CHex; Type=L2; Scaling: 1Hex
P606 Trg BitONblocked
Destination of the status bit 'Turn-ON locked' (status word 1, bit 6)
*
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=25EHex; Type=L2; Scaling: 1Hex
P607 Trg Bit Warning
Destination of the status bit 'Warning' (status word 1, bit 7)
*
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=25FHex; Type=L2; Scaling: 1Hex
P608 Trg Bit Deviat.
Destination wiring of the status bit "U
*
cf. P517
Parameter values, indices: as P600
PNU=260Hex; Type=L2; Scaling: 1Hex
P610 Trg Regen Ready
Destination wiring of the status bit "Regenerating ready" (status word 1,
*
Bit 10)
Parameter values, indices: as P600
PNU=260Hex; Type=L2; Scaling: 1Hex
P611 Trg Low Voltage
Destination of the status bit 'Undervoltage' (status word 1, bit 11)
*
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=263Hex; Type=L2; Scaling: 1Hex
5-24
ENGLISH
∧ 1
=
∧ 1
=
∧ 1
=
∧ 1
=
set = U act" (status word 1, bit 8) -
d d
∧ 1
=
∧ 1
=
∧ 1
=
Value range Display
[phys. unit] Indices
Selection text Factory-
setting
0 to 4212 2
i001=1002
i002=0
0 to 4212 2
0
0 to 4212 2
0
0 to 4212 2
(0)
0 to 4212 2
0
0 to 4212 2
0
0 to 4212 2
0
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
09.02
See
Modify
(access /
status)
2/ BR
2/ BR
3/ BR
3/ BR
3/ BR
3/ BR
2/ BR
2/ BR
3/ BR
3/ BR
3/ BR
3/ BR
3/ BR
3/ BR
