Siemens SIMOVERT Master Drives 6SE70 Betriebsanleitung Seite 369

09.02
PNU OP1S parameter name
Description
*
: Conf.
Par.
P574 Src Motor/Regen
Source for the "Generating/motoring" control command (control word 1, bit
*
14)
**
0: Control command ineffective (motoring and generating mode
permitted
1: Not allowed
Other values:
During circuit identification parameter value 0 must be set.
If a rectifier unit is present, this parameter is visible with effect from software
version * 4.4.
B/R parameter
PNU=23EHex; Type=L2; Scaling: 1Hex
P575 Src No ExtFault1
Source for the "External fault 1" control command (control word 1, bit 15)
*
L signal causes disconnection of the faulted drive.
0: Not allowed
1: No external fault 1
1003: Binary input 3 of the CUR board
Other values:
B/R parameter
PNU=23FHex; Type=L2; Scaling: 1Hex
P578 Src RDataSetBit0
Source for bit 0 (control word 2, bit 18) for selecting the reserve data set
*
(RDS)
0: RDS bit 0 has the value 0
1: RDS bit 0 has the value 1
Other values:
B/R parameter
PNU=242Hex; Type=L2; Scaling: 1Hex
P579 Src RDataSetBit1
Source for bit 1 (control word 2, bit 19) for selecting the reserve data set
*
(RDS)
0: RDS bit 1 has the value 0
1: RDS bit 1 has the value 1
Other values:
B/R parameter
PNU=243Hex; Type=L2; Scaling: 1Hex
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
∧ 1
=
see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
∧ 1
=
see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
∧ 1
=
see allowed settings in section 4.3.1.1 (process data
wiring of the control word)
∧ 1
=
Value range Display
[phys. unit] Indices
Selection text Factory-
setting
0 to 6005 2
0
1 to 6005 2
(1)
0 to 6005 2
0
0 to 6005 2
0
ENGLISH
Parameter List
See
Modify
(access /
status)
2/ BR
2/ BR
2/ BR
2/ BR
3/ BR
3/ BR
2/ BR
2/ BR
5-21
