06.01
2

Transport, Unpacking and Assembly

2.1 Transport and unpacking
The units are packed at the manufacturing works. A product packaging label is attached to the box.
Avoid extreme vibrations and hard impacts during transport, e.g. when lowering the unit.
Pay attention to the notes on the packaging relating to transport, storage and proper handling.
The converter can be installed after unpacking it and checking the consignment for completeness and
damage.
The units are bolted onto pallets with fixing pieces in their usual operating position and packed with
cardboard.
The packaging may be disposed of in accordance with local cardboard disposal regulations.
You should notify your freight forwarder immediately if you discover any transportation damage.
2.2

Storage

The units must be stored in clean dry rooms. Temperatures between −25 °C (−13 °F) and + 70 °C (158 °F) are
permissible. Temperature fluctuations > 20 K per hour are not permissible.
2.3

Assembly

The following are required for securing size H:
♦ four M8 bolts
♦ four M8 bolts
The following are required for securing size K:
♦ six M8 bolts
♦ dimension drawing (Figure 2.3 for size K)
For safe operation of the unit, it is presumed it will be assembled and commissioned by
qualified personnel, paying attention to the warning notes given in these operating
instructions.
Particular note must be taken both of the general and national erection and safety
regulations regarding work on power installations (e.g. VDE) and regulations regarding the
proper use of tools and of personal protective equipment.
Non-observance of warning notices can result in death, severe personal injury or
considerable property damage.
The unit must be protected against the ingress of foreign matter as otherwise proper
functioning and safety will not be guaranteed.
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
WARNING
ENGLISH
Transport, Unpacking and Assembly
2-1
