PNU OP1S parameter name
Description
*
: Conf.
Par.
r958 Warning Param 6
Warning Parameter 6 (CB-warnings)
If a warning (numbers 80 to 96) is active, the related segment in the display
is ON
96 94
95 93
88 86
87 85
PNU=3BEHex; Type=V2; Scaling: 1Hex
r959 Warning Param 7
Warning Parameter 6 (TB-warnings 1)
If a warning (numbers 97 to 112) is active, the related segment in the
display is ON
112 110
111
104 102
103
PNU=3BFHex; Type=V2; Scaling: 1Hex
r960 Warning Param 8
Warning Parameter 6 (TB-warnings 2)
If a warning (numbers 113 to 128) is active, the related segment in the
display is ON
128 126
127
120 118
119
PNU=3C0Hex; Type=V2; Scaling: 1Hex
r967 Control Word 1
Display parameter of control word 1 (bit 0-15)
Identical with r550 (control word 1)
PNU=3C7Hex; Type=V2; Scaling: 1Hex
r968 Status Word 1
Display parameter of status word 1 (bit 0-15)
Identical with r552 (status word 1)
PNU=3C8Hex; Type=V2; Scaling: 1Hex
P970 Factory Settings
Parameter reset to factory settings
*
0: Parameter reset: all parameters are reset to their original values
(factory settings). After this the parameter is reset to '1'.
1: no parameter reset
Note: This function can also be selected via P052=1.
PNU=3CAHex; Type=O2; Scaling: 1Hex
P971 EEPROM Storing
Passing of the parameter values of the RAM to the EEPROM on a change
*
from 0 auf 1.
It takes about 15s to process all of the values. During this time, the PMU
stays in the Values mode.
PNU=3CBHex; Type=O2; Scaling: 1Hex
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
92 90
91 89
84 82
83 81
∧ 1
=
108 106
107
109 105
100 98
101 99 97
∧ 1
=
124 122
125 123 121
116 114
117 115 113
∧ 1
=
∧ 1
=
∧ 1
=
∧ 1
=
∧ 1
=
Value range Display
[phys. unit] Indices
Selection text Factory-
setting
-
-
-
-
-
0 to 1 -
1
Param.Reset
Return
0 to 1 -
0
ENGLISH
Parameter List
See
Modify
(access /
status)
3/ BR
3/ BR
3/ BR
2/ BR
2/ BR
3/ B
3/ B
3/ BR
3/ BR
