Siemens SIMOVERT Master Drives 6SE70 Betriebsanleitung Seite 374

Parameter List
PNU OP1S parameter name
Description
*
: Conf.
Par.
P622 Trg Bit i2t Inv
Destination of the status bit 'Warning unit overload'
*
(status word 2, bit 22);
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=26EHex; Type=L2; Scaling: 1Hex
P623 Trg BitFltTmpInv
Destination of the status bit 'Fault unit overtemperature'
*
(status word 2, bit 23
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, Indices: as for P600
PNU=26FHex; Type=L2; Scaling: 1Hex
P624 Trg BitWarTmpInv
Destination of the status bit 'Warning unit overtemperature'
*
(status word 2, bit 24
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=270Hex; Type=L2; Scaling: 1Hex
P631 Trg Bit Charging
Destination of the status bit 'Charging active' (status word 2, bit 31)
*
Note:
For issuing the message via a terminal the active status (bit has H-level) is
inverted (broken wire proof).
Parameter values, indices: as P600
PNU=277Hex; Type=L2; Scaling: 1Hex
5-26
ENGLISH
∧ 1
=
∧ 1
=
∧ 1
=
∧ 1
=
Value range Display
[phys. unit] Indices
Selection text Factory-
setting
0 to 4212 2
0
0 to 4212 2
0
0 to 4212 2
0
0 to 4212 2
0
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
09.02
See
Modify
(access /
status)
3/ BR
3/ BR
3/ BR
3/ BR
3/ BR
3/ BR
3/ BR
3/ BR
