Siemens SIMOVERT Master Drives 6SE70 Betriebsanleitung Seite 249

09.02
Unit
Order No.
6SE70
38-2EH85-0AA0 630
41-0EH85-0AA0 800
37-7FH85-0AA0 560
41-0FH85-0AA0 800
37-7HH85-0AA0 560
41-0HH85-0AA0 800
41-3EK85-0AA0 630
41-8EK85-0AA0 800
41-3FK85-0AA0 560
41-5FK85-0AA0 710
41-8FK85-0AA0 800
41-3HK85-0AA0 560
41-5HK85-0AA0 710
41-8HK85-0AA0 800
Table 3.3 Built-in branch fuses
Table 3.3: Semiconductor protection only, lines are not reliably protected.
With these units, no external semiconductor protection is needed.
Line protection must be ensured for all device types by assigning a suitable line protection element (e.g. fuse,
line protection circuit-breaker) to the line cross-sectional area as defined in the currently valid standards – e.g.
DIN VDE 0100 Part 430.
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating instructions
Built-in branch fuses F11 to F16
Siemens SITOR
A Type
3NE3336
3NE3338-8
3NE3335
3NE3338-8
3NE3335
3NE3338-8
Built-in branch fuses F111 to F162
3NE3336
3NE3338-8
3NE3335
3NE3337-8
3NE3338-8
3NE3335
3NE3337-8
3NE3338-8
Bussmann
US standard
A Type
700 170M4717
900 170M5715
630 170M5696
900 170M5699
630 170M5696
900 170M5699
630 170M5696
630 170M5696
800 170M5698
630 170M5696
630 170M5696
800 170M5698
CAUTION
ENGLISH
Connection
3-5
