Start-Up
4.3.1.1.6 Selecting the source for control word 2 (bit 24-31)
Selection P. basic setting
Selection P. reserve setting
Value
Source
0000 Constant value = 0
0001 Constant value = 1
1001 CUR, BE1, -X101:9
1002 CUR, BE2, -X101:10
1003 CUR, BE3, -X101:11
1004 CUR, BE4, -X101:12
1005 CUR, BE5, -X101:13
1010 PMU
2001 SST1 (PMU -X300 or -X100:1...5)
Word1
2004 SST1 (PMU -X300 or -X100:1...5)
Word4
3001 CB/TB, Word1
3004 CB/TB, Word4
4101 SCI 1 and 2, Slave 1,BE1
4102 BE2
... Consecutively to
4110 BE10
4111 only SCI 2, Slave 1,BE11
4112 BE12
... Consecutively to
4116 BE16
4201 SCI 1 and 2,Slave 2,BE1
4202 BE2
... Consecutively to
4210 BE10
4211 only SCI 2, Slave 2,BE11
4212 BE12
... Consecutively to
4216 BE16
4501 SCB-SST (USS /Peer-t-Peer) Word1
4504 SCB-SST (USS /Peer-t-Peer) Word4
6001 SST2 (PTP1, A2-X117:1..5) Word 1
... Consecutively to
6005 SST2 (PTP1, A2-X117:1..5) Word 5
x: Value can be assigned for the selection parameters
Factory setting: X:
xG: for basic setting with P077=0
xR: for reserve setting with P077=0
4-16
ENGLISH
Bit 24
OPTIONS
for P590 / P591
25 26 27 28
586.1 587.1 588.1
586.2 587.2 588.2
xG/R
xG/R x xG/R xG/R
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
29 30 31
589.1 590 591
589.2 590 591
x
x X
x x x
x x x
x x x
x x x
x X x
x x
x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x
x x
x x
x x
