Hardware configuration (P052 = 4)

This function is used to select option boards (SCB, CB, TB) in the common rectifier electronics box.
In order to install these modules, an LBA bus coupling (Local Bus Adapter) is required for the electronics box
(see Section 9.1)!
All parameters, which can be written into the "Hardware configuration" status ("H", refer to the right-hand
column in the parameter list in Chapter 5), can be changed.
The "hardware configuration" selection can be realized in the "Switch-on inhibit", "Ready-to-switch" or "Fault"
status
Ablauf:
⇓
P052 = 4
⇓
P051 = 3
⇓
⇓
P090 =
P091 =
⇓
Additional parameters, depending on the option boards (refer to the associated Instruction
Manuals or Section 4.5)
⇓
P052 = 0
⇓
P key
⇓
After the selected function selection has been completed, the "Switch-on inhibit" (008) or
"Ready-to-switch-on" (009) operating display appears.
4-38
ENGLISH
Function selection Hardware configuration
Access stage Expert mode ( to change the following parameters)
Set the parameters to configure the optional board (see Section 4.5 or the
operating instructions for the board)
Board, slot 2 (To the RIGHT in the electronics box!)
Board, slot 3 (In the CENTER in the electronics box!)
Parameter values for P090/P091:
0:
1:
2:
3:
Function selection return
The operating display appears (r000) while parameters and interval variables
are being re-assigned
- The hardware is initialized
If error/fault message F050, F070 or F080 appears: see Chapter 7
No option board
CB Communications board
TB Technology board (only P090)
SCB Serial Communication Board
Common Rectifier
Siemens AG 6SE7087-6AK85-0AA0
Operating Instructions
09.02
