Download Or Upread (P052 = 3) - Siemens SIMOVERT Master Drives 6SE70 Betriebsanleitung

09.02
PWE MLFB
110 6SE7041-5HK85-0AA0
111 6SE7041-5FK85-0AA0
118 6SE7041-8EK85-0AA0
119 6SE7041-8HK85-0AA0
120 6SE7041-8FK85-0AA0
124 6SE7041-5EH85-0BA0
125 6SE7041-3FH85-0BA0
126 6SE7041-3HH85-0BA0
127 6SE7042-1EH85-0BA0
128 6SE7042-0FH85-0BA0
129 6SE7042-0HH85-0BA0
130 6SE7042-8EH85-0BA0
131 6SE7042-1HH85-0BA0
132 6SE7042-8FH85-0BA0
133 6SE7042-8HH85-0BA0
4.3.9.3 Download or upread
P052 has to be set to 3 when a "download" (write) or "upload" (read) has to be carried out for the parameters of
the common rectifier at the basic unit interface (SST1) using USS protocol (e.g. using SIMOVIS or OP1S).
"Upread/Download" can be selected in the following statuses: "Switch-on inhibit" (008), "Ready-to-switch-on"
(009) or "Fault" (007).
Procedure:
⇓
P052 = 3
⇓
P key
- Using a PC at the basic device interface SST1 and an appropriate application program (e.g.
SIMOVIS), it is possible to read and change all parameters independently of their operating
state and access level (P051).
⇓
P052 = 0
⇓
P key
⇓
After return, the operating display appears, "Switch-on inhibit" (008) or "Ready-to-switch-on"
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
Rated current Supply voltage
[A]
1464,0 3AC 660-690V
1464,0 3AC 500-600V
1780,0 3AC 380-480V
1880,0 3AC 660-690V
1880,0 3AC 500-600V
1500,0 3AC 380-480V
1300,0 3AC 500-600V
1300,0 3AC 660-690V
2100,0 3AC 380-480V
1950,0 3AC 500-600V
1950,0 3AC 660-690V
2850,0 3AC 380-480V
2100,0 3AC 660-690V
2850,0 3AC 500-600V
2850,0 3AC 660-690V
(P052 = 3)
Function selection "Upread/Download"
The operating display appears(021)
Function selection Return
(009)
BF
[V]
K
K
K
K
K
H
H
H
H
H
H
H
H
H
H
ENGLISH
Start-Up
4-37
