Options
9.6

DriveMonitor

The DriveMonitor software tool is provided for commissioning, parameterizing and diagnosing the common
rectifier via a PC.
DriveMonitor is supplied on the same CD-ROM as the operating instructions for the 6SE70 converter used in
conjunction with the common rectifier.
Order-No.: 6SX7010-0FA10
9.6.1

Installing the software

You can find a brief overview of the CD contents in START.HTM. If you have installed an HTML browser (e.g.
Internet Explorer or Netscape Navigator) on your PC, you can open the overview by double clicking on
START.HTM. If you do not have an HTML browser, you can find similar information in text format in file
README.TXT.
After you have chosen an installation language by selecting links DriveMonitor – Installation of DriveMonitor-
Start Installation, you can call the DriveMonitor installation routine.
Some Internet Browsers are not capable of starting programs directly. If this is the case on your PC, a
"Setup.exe - Save as" dialog appears after you select Start Installation.
You can then start the Setup program manually in sub-catalog
DriveMonitor\setup\setup.exe
Then follow the instructions displayed by the installation routine.
The default installation path for DriveMonitor is C:\DriveMon\P7VRVISX\System. A "DriveMonitor" icon is also
placed on your desktop.
9.6.2

Connection of common rectifier to a PC

The DriveMonitor software on the PC and the common rectifier are connected via the serial interface (X300 on
the PMU or X100 on the CUR board) and the USS protocol
Communication can be effected either via the terminal strip of the CUR-X100 (RS485 interface) or the
interface connector of the PMU-X300 (9-way SUB D connector, RS485-/RS232 interface).
It is only possible to operate one of the two possible connections (X100 or X300)!
9-8
ENGLISH
Only qualified personnel who are familiar with the DriveMonitor operating
instructions and with the operating instructions of the connected devices and
their safety instructions are permitted to intervene at the drive using the PC.
Incorrect use of the software can result in death, severe personal injury or
considerable property damage.
NOTE
WARNING
Siemens AG
Common Rectifier
09.02
6SE7087-6AK85-0AA0
Operating Instructions
