Commutating reactors: Selection of the power system commutating reactors with u
on Table 3.4 and Catalog DA93.1.
Fuses: Refer to Table 3.3. for fuse order numbers.
Output reactors in the DC circuit are not permitted (even with the parallel connection of power sections or in
12-pulse mode), because the DC link voltage is measured at the unit output terminals.
Function
Incoming supply terminals
Protective conductor
Power terminals
DC link voltage
(inverter)
Fan terminals
Table 3.1 Power connections
Terminal X19 fused with fuse (F3 and F4):
T7A/250V time-lag 6.3x32 mm (¼" x 1¼")
(19343-T7A/250V Messrs. Wickmann-Werke GmbH or 0034.5243 FST Messrs. Schurter)
Where the unit is operated in conjunction with a power system, one phase of which is
earthed and not the starpoint, the plant management must ensure that power supply to
the fan circuit (terminals X19-1, X19-2) and to the main contactor circuit (terminal X9-4,
X9-5) is taken from this phase and the starpoint.
Where this cannot be ensured, the power supply to the fan circuit and to the main
contactor circuit must be taken via an isolating transformer.
In addition, the power supply to terminals X19-1, X19-2, X9-4, X9-5 must be taken via an
isolating transformer, when:
• the connection to ground - electronic ground is interrupted (refer to Chapter 3.3.3
• the power supply unit is operated in conjunction with a non-grounded power supply
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating instructions
Terminal
X1-U1/L1
X1-V1/L2
X1-W1/L3
PE/GND
X1-C/L+
X1-D/L-
X19-1
X19-2
"Connection terminals on CUR card").
system.
NOTES
Connected load / Description
See Technical Data
Chapter 14
See Technical Data
Chapter 14
Supply connection for fan
230V AC ±10%, 50 to 60 Hz ±5%
Size H
Current consumption: at 50 Hz: 2.6 A, at 60 Hz: 3.3 A
Size K
Current consumption: at 50 Hz: 5.2 A, at 60 Hz: 6.6 A
WARNING
= 2% should be based
k
ENGLISH
Connection
