Fault and Alarm Messages
Alarm Parameter Description
No. No.
⎯⎯
Bit No.
A049
P956
no Slave
⎯⎯
In the case of serial I/O (SCB1 with SCI1/2), no
slave is connected and/or the fiber optic conductor
0
is interrupted or the slaves have no voltage.
A050
P956 Slave not ok
⎯⎯
In the case of serial I/O, the slaves required
according to the parameter settings are not
1
available (slave number an/or slave type).
A051
P956 Peer Bdrate
⎯⎯
In a peer-to-peer connection, the baud rate
selected is too high and/pr different
2
A052
P956 Peer PrD-L
⎯⎯
In a peer-to-peer connection, an excessive process
data length has been set (>5).
3
A053
P956 Peer Lng f.
⎯⎯
In a peer-to-peer connection, the process data
length of the sender and receiver do not agree
4
A065
P957 Auto Restart
⎯⎯
The line voltage is outside the tolerance band at
the moment (e.g. power outage). The firing pulses
0
are therefore inhibited. On power recovery,
however, the WEA option (P366) implements an
auto restart.
A081.. r958 CB Warning 1...16
⎯⎯
See user's manual for the CB module
A096
0...15
A097.. r959 TB Warning 1 16
A112
⎯⎯
See user's manual for the TB module
0...15
A113..
r960 TB Warning 17...32
A128
⎯⎯
See user's manual for the TB module
0...15
7-10
ENGLISH
Countermeasures
P660 SCI AnalogInConf
Check the slave.
Check the cable.
Check P660 SCI AnalogInConf
Match the baud rates of the SCB modules connected to
each ( P684 SST/SCB Baudrate)
Reduce the number of words
P686 SCom/SCB # PrDat .
Match the word lengths of the sender and receiver
P686 SCom/SCB # PrDat
Important
An auto restart may constitute a danger for persons and
property. Make sure you really want to have auto restart
(WEA).
If necessary, change P366 WEA .
