Logbook

The logbook must be kept up-to-date by the operating personnel.
All service and maintenance work carried out on the common rectifier should be entered briefly in keywords into
the logbook.
The software used for common rectifier is identical to that used for the rectifier/regenerating units of the
equipment series 6SE70.
The functional difference between common rectifier and rectifier/regenerating units is defined by means of the
parameter P070.
All the parameters are listed in this chapter. Parameters, which are not employed for the common rectifier
(designated by **" in the parameter list of Chapter 5), should be ignored.
Continuous entries are important for maintenance and could be significant when it comes to warranty claims.
Similarly, in the event of software upgrading, it is important that a record of the parameter settings is available,
because during this procedure all values are reset to their original factory settings.
Location: ........................................................
Start-up settings
Start-up settings
change
Par- Parameter
No. designation
P050 Language
P051 Access Level
P052 Function select
P053 Parameter Access
P054 Display Light
P070 MLFB(6SE70 ... )
P071 Line Volts
P074 Limit LowVoltage
P075 Rtd Amps
P076 Config. PCircuit
P077 Factory set.type
P090 Board Position 2
P091 Board Position 3
P140 Rectifier Resist
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
Date Name
Factory setting
0
2
0
6
0
0
dependent on P070
61
dependent on P070
002
0
0
0
i001=0.000
i002=0.000
i003=0.000
i004=0.000
NOTE
Unit Order No.: ...................................................
Serial No.: ...................................................
Department
Start-up setting
i001=
i002=
i003=
i004=
Logbook
Signature
Start-up setting
change
i001=
i002=
i003=
i004=
12-1
