09.02
PNU OP1S parameter name
Description
*
: Conf.
Par.
5.9

Setpoint channel

P486 Src Current Setp
Setpoint source
*
Parameter values:
As per PZD wiring of the setpoint channel (see Section 4.3.1.3)
Only effective if slave drive (control word 2, bit 27 =1)
G/R parameter
PNU=1E6Hex; Type=L2; Scaling: 1Hex
P517 DC Volts Dev Lim
Setpoint/actual-value deviation of Ud:
If the deviation between the Ud setpoint and the actual Ud is considerable,
the "Setpoint/actual-value deviation" message is generated (status word 1
Bit 8 (r552))
Compare P518 (min. duration of deviation)
RDS- parameter
PNU=205Hex; Type=O2; Scaling: 1Hex
P518 Deviation Time
Min. deviation time:
If there is a deviation (P517), the "Setpoint/actual-value deviation" message
(status word 1 bit 8 (r552)) is generated after this minimum time has
elapsed
RDS parameter
PNU=206Hex; Type=O2; Scaling: 1Hex
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
∧ 1
=
∧ 0.01
=
∧ 0.01
=
Value range Display
[phys. unit] Indices
Selection text Factory-
setting
0 to 6005 2
(0)
0.00 to 100.00 4
2.00
[%] of 1.35 P071
*
0.00 to 10.00 4
[s] 0.10
ENGLISH
Parameter List
See
Modify
(access /
status)
3/ BR
3/ BR
3/ BR
3/ B
3/ BR
3/ B
5-17
