PNU OP1S parameter name
Description
*
: Conf.
Par.
r730 SCB Diagnostics
SCB diagnostics
All values in HEX display
If a quantity is represented, overflow takes place at FF Hex.
The meaning of several Indices depends of the selected SCB protocol
(P682).
i001: flTC
i002: Terr
i003: Ferr
i004: Orun
i005: Prty
i006: STX
i007: ETX
i008: BCC
i009: L/KL
i010: T/An
i011: BCd0
i012: BCd1
i013: Warn
i014: Sl1?
i015: Sl2?
i016: IniF:
PNU=2DAHex; Type=L2; Scaling: 1Hex
r731 CB/TB Diagnostics
For detailed information see manuals of the used communication boards
(CB) or technology boards (TB).
PNU=2DBHex; Type=L2; Scaling: 1Hex
r748 Fault Time
The instants at which faults occur (reading of the hours counter r013 at the
instant the fault occurs)
See parameter r947 for details
Trip description by:
PNU=2ECHex; Type=O2; Scaling: 1Hex
Siemens AG 6SE7087-6AK85-0AA0
Common Rectifier Operating Instructions
Number of error-free telegrams
Number of error telegrams
Number of byte frame-errors
Number of overrun errors
Parity error
STX error
ETX error
Block check error
USS/Peer to Peer: incorrect telegram length
SCI modules: required maximum number of terminals
according to process data wiring (P554 to P631).
USS: Timeout
SCI Modules: required analog inputs / outputs
according to process data wiring of the setpoint
channel and actual value output via SCI (P664) .
PCB code word 0
PCB code word 1
SCB-DPR- warning word
Information, if slave 1 needed and if yes, which type.
0: no slave needed
1: SCI1
2: SCI2
Information, if slave 2 needed and if yes, which type.
0: no slave needed
1: SCI1
2: SCI2
with 'SCI modules': initialization fault
∧ 1
=
∧ 1
=
r947 Fault number
r949 Fault value
r951 List of fault texts
P952 Number of faults
∧ 1
=
Value range Display
[phys. unit] Indices
Selection text Factory-
setting
16
32
24
ENGLISH
Parameter List
See
Modify
(access /
status)
3/ HBR
