Siemens SIMOVERT Master Drives 6SE70 Betriebsanleitung Seite 368

Parameter List
PNU OP1S parameter name
Description
*
: Conf.
Par.
P568 Src Jog1 ON
Source of the 'Jog 1' command (control word 1, bit 8)
*
0: No Jog operation
1: Not allowed
Other values: see allowed settings in Section 4.3.1.1 (process data
B/R-Parameter
PNU=238Hex; Type=L2; Scaling: 1Hex
P569 Src Jog2 ON
Source of the 'Jog 2' command (control word 1, bit 9)
*
Description see P568
B/R parameter
PNU=239Hex; Type=L2; Scaling: 1Hex
P571 Src Reduce DC V
Source for the "Reduce U d " control command (control word 1, bit 11)
*
Wait for U d reduction
0: U d reduction inactive
1: U d reduction requested (permanent U d reduction)
other values: see allowed settings in Section 4.3.1.1 (process data
B/R parameter
PNU=23BHex; Type=L2; Scaling: 1Hex
P572 Src RegenRelease
Source for the "Regenerating enable" control command (control word 1, bit
*
12)
**
0: Regenerating inhibited
1: Regenerating enabled
Other values: see allowed settings in Section 4.3.1.1 (process data
B/R parameter
PNU=23CHex; Type=L2; Scaling: 1Hex
P573 Src No ExtFault3
Source for the "External fault 3" control command (control word 1, bit 13)
*
L signal causes disconnection of the faulted drive.
0: Not allowed
1: No external fault 3
1003: Binary input 3 of the CUR board
Other values: see allowed settings in Section 4.3.1.1 (process data
B/R parameter
PNU=23DHex; Type=L2; Scaling: 1Hex
