Parameterization and configuration
8.2.1 Object 6000h – Operating parameters
This object defines whether rising or falling position values are output when the
magnet moves towards the end of the rod.
Index
Name
Data type
Value range
Default value
Bit structure
Bit
0-1
2
3
4 - 15 reserved
8.2.2 Object 6002h – Total measuring range in measuring units
Defines the total number of steps of the measuring system related to the measuring
length, which is stored in the measuring system.
Index
Name
Data type
Value range
Default value
Default value:
The measuring length indicated on the name plate multiplied with 1000, according to
the resolution of 0.001 mm
Total measuring range in measuring units =
 TR-Electronic GmbH 2010, All Rights Reserved
Page 166 of 183
0x6000
Operating parameters
UNSIGNED16
0x04 = Position rising
0x0C = Position falling
0x04
Function Bit = 0
reserved
Scaling function is set to 1, can not be changed!
increasing, if the magnet is
Code Sequence
moved to the rod end
0x6002
Total measuring range
UNSIGNED32
0...0xFF FF FF FF
see below
TR - ELA - BA - DGB - 0016 - 04
Object type VAR
Category Mandatory
Access rw
PDO mapping no
Bit = 1
decreasing, if the magnet is
moved to the rod end
Object type VAR
Category Mandatory
Access rw
PDO mapping no
Measuring length
Resolution in mm
