CANopen information

3.9.5.5 Inquire Node-ID protocol

The given protocol has implemented the Inquire Node-ID service. By means of
the LSS master the Node-ID of a single LSS slave in the network can be read-out.
Only one device is to be switched into LSS configuration state.
LSS-Master --> LSS-Slave
0
COB-ID CS
0x7E5 94
LSS-Slave --> LSS-Master
0
COB-ID CS
0x7E4 94
Node-ID
Corresponds the Node-ID of the selected device.
 TR-Electronic GmbH 2010, All Rights Reserved
Page 136 of 183
1 2
1 2
Node-ID
1...127
TR - ELA - BA - DGB - 0016 - 04
3 4 5
Reserved by CiA
3 4 5
Reserved by CiA
6 7
6 7
