CANopen information
3.9.5 Inquire LSS address protocols
3.9.5.1 Inquire identity Vendor-ID protocol
The given protocol has implemented the Inquire LSS address service. By
means of the LSS master the Vendor-ID of a single LSS slave in the network can be
read-out. Only one device is to be switched into LSS configuration state.
LSS-Master --> LSS-Slave
0
COB-ID
CS
0x7E5
90
LSS-Slave --> LSS-Master
0
COB-ID
CS
0x7E4
90
3.9.5.2 Inquire identity Product-Code protocol
The given protocol has implemented the Inquire LSS address service. By
means of the LSS master the Product-Code of a single LSS slave in the network can
be read-out. Only one device is to be switched into LSS configuration state.
LSS-Master --> LSS-Slave
0
COB-ID
CS
0x7E5
91
LSS-Slave --> LSS-Master
0
COB-ID
CS
0x7E4
91
TR-Electronic GmbH 2010, All Rights Reserved
Page 134 of 183
1
2
1
2
Vendor-ID (≙Index 1018h:01)
LSB
1
2
1
2
Product-Code (≙Index 1018h:02)
LSB
TR - ELA - BA - DGB - 0016 - 04
3
4
Reserved by CiA
3
4
MSB
3
4
Reserved by CiA
3
4
MSB
5
6
5
6
Reserved by CiA
5
6
5
6
Reserved by CiA
Printed in the Federal Republic of Germany
01/20/2017
7
7
7
7
