Communication specific standard objects (CiA DS-301)

7.11 Object 1010h: Store parameters

This object supports the saving of parameters in non volatile memory (EEPROM).
Index
1010h
Sub-Index0
Sub-Index1:
Unsigned32
Bits
Value
By read access the device provides information about its saving capability.
Bit 0 = 1, the device saves parameters only on command. That means, if parameters
have been changed by the user and no "Store Parameter Command" had been
executed, at the next power on, the parameters will have there old values.
In order to avoid storage of parameters by mistake, storage is only executed when a
specific signature is written to the object. The signature is "save".
Unsigned32
MSB
On reception of the correct signature, the device stores the parameters. If the storing
failed, the device responds with abort domain transfer: Error code 0606 0000h.
If a wrong signature is written, the device refuses to store and responds with abort
domain transfer: 0800 0020h.
 TR-Electronic GmbH 2010, All Rights Reserved
Page 156 of 183
Sub-Index Comment
0 largest supported Sub-Index
1 save all parameters
: The entry at sub-index 0 contains the largest Sub-Index that is
(only read)
supported. Value = 1.
Contains the save command.
MSB
e v
65h 76h
TR - ELA - BA - DGB - 0016 - 04
31-2
= 0
a
61h
Type
Unsigned8
Unsigned32
LSB
1 0
0 1
LSB
s
73h
