CANopen information
3.8.5 Inquire LMT address protocols
3.8.5.1 Inquire Manufacturer-Name protocol
The given protocol has implemented the Inquire LMT address service. By means
of the LMT master the Manufacturer-Name of a single LMT slave in the network can be
read-out. Only one device is to be switched into Configuration Mode.
LMT-Master --> LMT-Slave
0
COB-ID
CS
0x7E5
36
LMT-Slave --> LMT-Master
0
COB-ID
CS
0x7E4
36
Manufacturer-Name = „TR-ELEC"
M1...M7 =
3.8.5.2 Inquire Product-Name protocol
The given protocol has implemented the Inquire LMT address service. By
means of the LMT master the Product-Name of a single LMT slave in the network can
be read-out. Only one device is to be switched into Configuration Mode.
LMT-Master --> LMT-Slave
0
COB-ID
CS
0x7E5
37
LMT-Slave --> LMT-Master
0
COB-ID
CS
0x7E4
37
Product-Name =
P1...P7 =
TR-Electronic GmbH 2010, All Rights Reserved
Page 124 of 183
1
2
1
2
Manufacturer-Name (ASCII)
M1
M2
0x54, 0x52, 0x2D, 0x45, 0x4C, 0x45, 0x43
1
2
1
2
P1
P2
LMP30, LA46 or LP46
LMP30 = 0x4C, 0x4D, 0x50, 0x33, 0x30, 0x00, 0x00
LA46 =
LP46 =
TR - ELA - BA - DGB - 0016 - 04
3
4
Reserved by CiA
3
4
M3
M4
3
4
Reserved by CiA
3
4
Product-Name (ASCII)
P3
P4
0x4C, 0x41, 0x34, 0x36, 0x00, 0x00, 0x00
0x4C, 0x50, 0x34, 0x36, 0x00, 0x00, 0x00
5
6
5
6
M5
M6
5
6
5
6
P5
P6
Printed in the Federal Republic of Germany
01/20/2017
7
7
M7
7
7
P7
