3.8.5.3 Inquire Serial-Number protocol

The given protocol has implemented the Inquire LMT address service. By
means of the LMT master the Serial-No. of a single LMT slave in the network can be
read-out. Only one device is to be switched into Configuration Mode.
LMT-Master --> LMT-Slave
0
COB-ID CS
0x7E5 38
LMT-Slave --> LMT-Master
0
COB-ID CS
0x7E4 38
Serial-No. =
S1...S7 =
Printed in the Federal Republic of Germany
01/20/2017
1 2
1 2
S1 S2
e.g. "02"
BCD coded
TR - ELA - BA - DGB - 0016 - 04
3 4
Reserved by CiA
3 4
Serial-No. (BCD)
S3 S4
5 6
5 6
S5 S6
 TR-Electronic GmbH 2010, All Rights Reserved
Page 125 of 183
7
7
S7
