Parameterization and configuration
8.1.1 Object 2000h – COB-ID for boot-up message
This object configures the COB-ID which is transmitted when the measuring system
starts up (Switch-on time/RESET NODE) and is used to signal that the slave has
entered the state PRE-OPERATIONAL after the state INITIALIZING. Valid values are
000h to 7FFh, default value = 700h.
By means of bit 2
Unsigned16
8.1.2 Object 2001h – Parameter auto store
This object supports the automatic storing of all objects. In this case changed
parameters do not have to be stored permanently by means of object 1010h "Store
parameters". Default value = 0.
Unsigned8
TR-Electronic GmbH 2010, All Rights Reserved
Page 162 of 183
15
this function can be enabled/disabled:
15
Bit 2
= 0:
Written value into bits 2
configured is used.
15
Bit 2
= 1:
Written value into bits 2
message is transmitted.
COB-ID for Boot-Up Message
Byte 0
7
0
2
to 2
00h – FFh
0
Bit 2
= 0:
No automatic storing. Parameters which are not stored with write access must
be stored permanently by means of object 1010h.
0
Bit 2
= 1:
Automatic storing of all changed parameters.
Auto store
Byte 0
7
0
2
to 2
TR - ELA - BA - DGB - 0016 - 04
0
10
to 2
are valid, with the next start up the COB-ID
0
10
to 2
are not valid, with the next start up no boot-up
10
2
to 2
0h – 7h
Byte 1
8
11
14
2
to 2
0h
Printed in the Federal Republic of Germany
01/20/2017
15
2
0-1
