3.5.3 Write SDO

Initiate Domain Download
Request Protocol format:
Byte
Contents Code
Format Byte 0:
MSB
7
0
n = number of data bytes (bytes 4-7) that does not contain data.
If only 1 data byte (Data 0) contains data the value of byte 0 is "2FH".
The Write SDO telegram has to be send to the slave.
The slave answers with the following telegram:
Response Protocol format:
Byte
Contents Code
If byte 0 = 80h the transfer has been aborted.
Printed in the Federal Republic of Germany
01/20/2017
COB-Identifier = 600h + Node-ID
0 1 2
Index
2xh Low High
6 5 4 3
0 1 0 n
COB-Identifier = 580h + Node-ID
0 1 2
Index
60h Low High
TR - ELA - BA - DGB - 0016 - 04
Write SDO´s
3 4
Sub-
Data 0 Data 1 Data 2 Data 3
Index
Byte 0
LSB
2 1 0
1 1
Read SDO´s
3 4
Sub-
Data 0 Data 1 Data 2 Data 3
Index
Byte 0
5 6 7
0 0 0
5 6 7
0 0 0
