en
8
1
Fig. 15
►
Insert the endoscope 5/obturator for optical
channel 8 as far as the stop or until the locking
pin 6 or 9 clicks into place, so that the
endoscope 5/obturator for optical channel 8 can
only be removed by activating the release button 3.
10
8.2
►
9
3
Fig. 16
Inserting the obturator for the
oval working channel
Hold the obturator for the oval working channel 7
at the distal end and carefully insert it into the
working channel 12 as far as the stop, see Fig. 16.
Due to friction in the channel, the obturator is
secured from falling out.
7
