Quertransport · Transverse conveyor · 横向输送线
BS 2/T
b
00016779.eps
Bandstrecke BS 2/T
BS 2/T belt section
BS 2/T 型皮带输送段
60 kg
b l
[mm] [mm]
160 320-6000
240 320-6000
320
320-6000
400 320-6000
480 320-6000
640 320-6000
800 320-6000
UB: Übertrieb für HQ 2-Baugröße
1)
BG 1 oder BG 2.
l
v U, f
N
[m/min]  11-127
0; 6 12; 15; 18
0; 6 12; 15; 18
0; 6 12; 15; 18
0; 6 12; 15; 18
0; 6 12; 15; 18
0; 6 12; 15; 18
0; 6 12; 15; 18
UB: connection belt for HQ 2 size
1)
BG 1 or BG 2.
Bosch Rexroth AG
MA = R
AT MA ZA UB
1)
S; K R; L N, A 1
S; K R; L N, A 1
S; K R; L; M N, A 1
S; K R; L; M N, A 1;2
S; K R; L; M N, A 1;2
S; K R; L; M N, A 2
S; K R; L; M N, A 2
UB： 连接套件，用于 HQ 2，尺寸 BG 1
1)
或 BG 2。
5–23
1
2
3
4
5
6
7
8
Nr./No./编号
9
3 842 999 722
b = ... mm
l = ... mm
10
v = ... m/min
N
U = ... V
f = ... Hz
AT = ...
11
MA = ...
ZA = ...
UB = ...
12
13
14
15
16
