ADJUSTING THE FOOTREST

The footrest is adjustable to allow for elevation of the patient's legs (see Figure 33) .
To raise the footrest, lift the foot rest frame (A) as high as possible until it locks into place . The support bracket
engages automatically when released .
To lower the footrest, lift the foot rest frame (A) and, while holding the frame, lift up on the release handle (B) until the
bracket disengages . Carefully lower the footrest until it rests flat .
A
B
Foot End
Figure 33: Footrest Elevated
