Control Techniques Unidrive sp Kurzhandbuch Seite 9

Safety Product Mechanical
Information Information Installation
Table 2-1 Parts supplied with the drive
Description Size 0
Control
connectors
Relay
connector
UL warning
label
Grounding
bracket
Through panel
mounting
gasket
Through panel
mounting
bracket
Surface
mounting
brackets
Top surface
mounting
brackets
Nylon
washers
Sealing clips
Fixing
screws
Grounding
clamp
Ground
cable bridge
DC terminal
cover
grommets
Ferrite ring
Supply and
motor
connector
Ground fixing
M6x12
screws
Fan supply
connector
IP54 gasket
IP54 insert
Unidrive SP Short Form Guide
Issue Number: 2
Electrical Getting
Menu 0
Installation Started
Size 1 Size 2
M6
M6
www.controltechniques.com
Running Advanced
the motor parameters
Size 3 Size 4
CAUTION
Risk of Electric Shock
Power down unit 10minutes
before removing cover
M6
UL Listing
Diagnostics Appendix
Information
Size 5 Size 6
M8
M6
M8x20
9
