Trip
Drive encoder trip: The number of periods per revolution calculated from encoder data
Enc15
during auto-configuration is either less than 2 or greater than 50,000.
Linear motor pole pitch / encoder ppr set up is incorrect or out of parameter range
165 i.e. Pr 5.36 = 0 or Pr 21.31 = 0.
Faulty encoder.
Drive encoder trip: EnDat encoder - The number of comms bits per period for a linear
Enc16
encoder exceeds 255.
Select a different type of encoder.
166
Faulty encoder.
Drive encoder trip: The periods per revolution obtained during auto-configuration for a
Enc17
rotary SINCOS encoder is not a power of two.
Select a different type of encoder.
167
Faulty encoder.
ENP.Er Data error from electronic nameplate stored in selected position feedback device
176 Replace feedback device
Et External trip from input on terminal 31
Check terminal 31 signal
Check value of Pr 10.32
6
Enter 12001 in Pr xx.00 and check for parameter controlling Pr 10.32
Ensure Pr 10.32 or Pr 10.38 (=6) are not being controlled by serial comms
HF01 Data processing error: CPU address error
Hardware fault - return drive to supplier
HF02 Data processing error: DMAC address error
Hardware fault - return drive to supplier
HF03 Data processing error: Illegal instruction
Hardware fault - return drive to supplier
HF04 Data processing error: Illegal slot instruction
Hardware fault - return drive to supplier
HF05 Data processing error: Undefined exception
Hardware fault - return drive to supplier
HF06 Data processing error: Reserved exception
Hardware fault - return drive to supplier
HF07 Data processing error: Watchdog failure
Hardware fault - return drive to supplier
HF08 Data processing error: Level 4 crash
Hardware fault - return drive to supplier
HF09 Data processing error: Heap overflow
Hardware fault - return drive to supplier
HF10 Data processing error: Router error
Hardware fault - return drive to supplier
HF11 Data processing error: Access to EEPROM failed
Hardware fault - return drive to supplier
HF12 Data processing error: Main program stack overflow
Hardware fault - return drive to supplier
HF13 Data processing error: Software incompatible with hardware
Hardware or software fault - return drive to supplier
HF17 Multi-module system thermistor open or short circuit
217 Hardware fault - return drive to supplier
HF18 Multi-module system interconnect cable error
218 Hardware fault - return drive to supplier
