Trip
SCL Drive RS485 serial comms loss to remote keypad
Refit the cable between the drive and keypad
Check cable for damage
30
Replace cable
Replace keypad
SLX.dF Solutions Module slot X trip: Solutions Module type fitted in slot X changed
204, 209,
Save parameters and reset
214
SLX.Er Solutions Module slot X trip: Solutions Module in slot X has detected a fault
202, 207, Check value in Pr 15/16/17.50. See the Diagnostics section in the relevant Solutions Module
212 User Guide for more information.
SLX.HF Solutions Module slot X trip: Solutions Module X hardware fault
200, 205, Ensure Solutions Module is fitted correctly
210 Return Solutions Module to supplier
SLX.nF Solutions Module slot X trip: Solutions Module has been removed
Ensure Solutions Module is fitted correctly
203, 208,
Re-fit Solutions Module
213
Save parameters and reset drive
Solutions Module trip: Drive mode has changed and Solutions Module parameter routing
SL.rtd
is now incorrect
Press reset.
215
If the trip persists, contact the supplier of the drive.
SLX.tO Solutions Module slot X trip: Solutions Module watchdog timeout
201,206,21 Press reset.
1 If the trip persists, contact the supplier of the drive.
t038
User trip defined in 2
38 SM-Applications program must be interrogated to find the cause of this trip
t040 to t089
User trip defined in 2
40 to 89 SM-Applications program must be interrogated to find the cause of this trip
t099
User trip defined in 2
99 SM-Applications program must be interrogated to find the cause of this trip
t101
User trip defined in 2
101 SM-Applications program must be interrogated to find the cause of this trip
t112 to t160
User trip defined in 2
112 to 160 SM-Applications program must be interrogated to find the cause of this trip
t168 to t174
User trip defined in 2
168 to 174 SM-Applications program must be interrogated to find the cause of this trip
t216
User trip defined in 2
216 SM-Applications program must be interrogated to find the cause of this trip
th Motor thermistor trip
Check motor temperature
24 Check thermistor continuity
Set Pr 7.15 = VOLt and reset the drive to disable this function
thS Motor thermistor short circuit
Check motor thermistor wiring
25 Replace motor / motor thermistor
Set Pr 7.15 = VOLt and reset the drive to disable this function
tunE* Autotune stopped before completion
The drive has tripped out during the autotune
18 The red stop key has been pressed during the autotune
The secure disable signal (terminal 31) was active during the autotune procedure
