Field wiring connectors
Sizes 4 to 6
• UL listed wire connectors are used for terminating power circuit field wiring, e.g.
Ilsco TA series
AC supply specification
The drive is suitable for use in a circuit capable of delivering not more than 100,000rms
symmetrical Amperes at 264Vac rms maximum (200V drives), 528Vac rms maximum
(400V drives) or 600Vac rms maximum (575V and 690V drives).
Maximum continuous output current
The drive models are listed as having the maximum continuous output currents (FLC)
shown in Table 11-1, Table 11-2, Table 11-3 and Table 11-4.
Table 11-1 Maximum continuous output current (200V drives)
Model
SP1201
SP1202
SP1203
SP1204
SP2201
SP2202
SP2203
Table 11-2 Maximum continuous output current (400V drives)
Model
SP1401
SP1402
SP1403
SP1404
SP1405
SP1406
SP2401
SP2402
SP2403
SP2404
Table 11-3 Maximum continuous output current (575V drives)
Model
SP3501
SP3502
SP3503
SP3504
350
Electrical Getting
Menu 0
Information Started
FLC (A)
5.2
6.8
9.6
11
15.5
22
28
FLC (A)
2.8
3.8
5.0
6.9
8.8
11
15.3
21
29
29
FLC (A)
5.4
6.1
8.3
11
www.controltechniques.com
Running Advanced
Diagnostics Appendix
the motor parameters
Model FLC (A)
SP3201 42
SP3202 54
SP4201 68
SP4202 80
SP4203 104
SP5201 130
SP5202 154
Model FLC (A)
SP3401 35
SP3402 43
SP3403 56
SP4401 68
SP4402 83
SP4403 104
SP5401 138
SP5402 168
SP6401 205
SP6402 236
Model FLC (A)
SP3505 16
SP3506 22
SP3507 27
