SM-Keypad Plus set-up menus
Table 5-1 Menu 40 parameter descriptions
40.00
40.01
40.02
40.03
40.04
40.05
40.06
40.07
40.08
40.09
40.10
40.11
40.12
40.13
40.14
40.15
40.16
40.17
40.18
40.19
40.20
40.21
40.22
Table 5-2 Menu 41 parameter descriptions
41.00
41.01 to
41.50
41.51
5.6

Changing the operating mode

Changing the operating mode returns all parameters to their default value, including the
motor parameters. (Pr 0.49 Security status and Pr 0.34 User security code are not
affected by this procedure.)
Procedure
Use the following procedure only if a different operating mode is required:
1. Ensure the drive is not enabled, i.e. terminal 31 is open or Pr 6.15 is Off (0)
2. Enter either of the following values in Pr 0.00, as appropriate:
1253 (Europe, 50Hz AC supply frequency)
1254 (USA, 60Hz AC supply frequency)
Unidrive SP Short Form Guide
Issue Number: 2
Electrical Getting
Installation Started
Parameter
Parameter 0
Language selection
Software version
Save to flash
LCD contrast
Drive and attribute database upload was
bypassed
Browsing favourites control
Keypad security code
Communication channel selection
Hardware key code
Drive node ID (Address)
Flash ROM memory size
Replacement macro enable
Replacement macro number
Wizard macro enable
Wizard macro number
Assistance on action macro enable
Assistance on action macro number
Assistance on action threshold parameter
String database version number
Screen saver strings and enable
Screen saver interval
Turbo browse time interval
Parameter
Parameter 0
Browsing filter source F01 to F50
Browsing favourites control
