5.11.3 User Security
The User Security, when set, prevents write access to any of the parameters (other than
Pr. 0.49 and Pr 11.44 Access Level) in any menu.
User security open - All parameters: Read / Write access
Pr 0.00
Pr 0.01
Pr 0.02
Pr 0.03
Pr 0.49
Pr 0.50
User security closed
Pr 0.00
Pr 0.01
Pr 0.02
Pr 0.03
Pr 0.49
Pr 0.50
Setting User Security
Enter a value between 1 and 999 in Pr 0.34 and press the
has now been set to this value. In order to activate the security, the Access level must
be set to Loc in Pr 0.49. When the drive is reset, the security code will have been
activated and the drive returns to Access Level L1. The value of Pr 0.34 will return to 0
in order to hide the security code. At this point, the only parameter that can be changed
by the user is the Access Level Pr 0.49.
Unlocking User Security
Select a read write parameter to be edited and press the
will now show CodE. Use the arrow buttons to set the security code and press the
button.
With the correct security code entered, the display will revert to the parameter selected
in edit mode.
If an incorrect security code is entered the display will revert to parameter view mode.
To lock the User Security again, set Pr 0.49 to Loc and press the
Disabling User Security
Unlock the previously set security code as detailed above. Set Pr 0.34 to 0 and press
the button. The User Security has now been disabled, and will not have to be
unlocked each time the drive is powered up to allow read / write access to the
parameters.
Unidrive SP Short Form Guide
Issue Number: 2
Electrical Getting
Installation Started
Pr 1.00 ............ Pr 21.00
Pr 1.01 ............ Pr 21.01
Pr 1.02 ............ Pr 21.02
Pr 1.03 ............ Pr 21.03
............
............
Pr 1.49 ............ Pr 21.30
Pr 1.50 ............ Pr 21.31
- All parameters: Read Only access
(except Pr 0.49
Pr 1.00 ............ Pr 21.00
Pr 1.01 ............ Pr 21.01
Pr 1.02 ............ Pr 21.02
Pr 1.03 ............ Pr 21.03
............
............
Pr 1.49 ............ Pr 21.30
Pr 1.50 ............ Pr 21.31
www.controltechniques.com
Running Advanced
Menu 0
the motor parameters
Pr 22.00
Pr 22.01
Pr 22.02
Pr 22.03
Pr 22.28
Pr 22.29
and Pr 11.44 )
Pr 22.00
Pr 22.01
Pr 22.02
Pr 22.03
Pr 22.28
Pr 22.29
UL Listing
Diagnostics Appendix
Information
button; the security code
button, the upper display
reset button.
