Trip
Power module DC bus voltage has exceeded the peak level or the maximum continuous
OV.P
level for 15 seconds
Increase deceleration ramp (Pr 0.04)
Decrease braking resistor value (staying above the minimum value)
Check nominal AC supply level
Check for supply disturbances which could cause the DC bus to rise – voltage overshoot after
supply recovery from a notch induced by DC drives.
Check motor insulation
106
Drive voltage rating
200
400
575
690
If the drive is operating in low voltage DC mode the overvoltage trip level is 1.45 x Pr 6.46.
Keypad has been removed when the drive is receiving the speed reference from the
PAd
keypad
Fit keypad and reset
34
Change speed reference selector to select speed reference from another source
PH AC voltage input phase loss or large supply imbalance detected
Ensure all three phases are present and balanced
Check input voltage levels are correct (at full load)
32
NOTE
conditions. The drive will attempt to stop the motor before this trip is initiated.
PH.P Power module phase loss detection
Ensure all three phases are present and balanced
107
Check input voltage levels are correct (at full load)
PS Internal power supply fault
Remove any Solutions Modules and reset
5 Check integrity of interface ribbon cables and connections (size 4,5,6 only)
Hardware fault - return drive to supplier
PS.10V 10V user power supply current greater than 10mA
Check wiring to terminal 4
8
Reduce load on terminal 4
PS.24V 24V internal power supply overload
The total user load of the drive and Solutions Modules has exceeded the internal 24V power
supply limit.
The user load consists of the drive's digital outputs, the SM-I/O Plus digital outputs, the drive's
9 main encoder supply and the SM-Universal Encoder Plus encoder supply.
• Reduce load and reset
• Provide an external 24V >50W power supply
• Remove any Solutions Modules and reset
PS.P Power module power supply fail
Remove any Solutions Modules and reset
108 Check integrity of interface ribbon cables and connections (size 4,5,6 only)
Hardware fault - return drive to supplier
PSAVE.Er Power down save parameters in the EEPROM are corrupt
Indicates that the power was removed when power down save parameters were being saved.
The drive will revert back to the power down parameter set that was last saved successfully.
37
Perform a user save (Pr xx.00 to 1000 or 1001 and reset the drive) or power down the drive
normally to ensure this trip does or occur the next time the drive is powered up.
Failure to measure resistance during autotune or when starting in open loop vector mode
rS
0 or 3
33 Check motor power connection continuity
SAVE.Er User save parameters in the EEPROM are corrupt
Indicates that the power was removed when user parameters were being saved.
The drive will revert back to the user parameter set that was last saved successfully.
36
Perform a user save (Pr xx.00 to 1000 or 1001 and reset the drive) to ensure this trip does or
occur the next time the drive is powered up.
52
Electrical Getting
Menu 0
Installation Started
Peak voltage
415
830
990
1190
N
Load level must be between 50 and 100% for the drive to trip under phase loss
www.controltechniques.com
Running Advanced
Diagnostics
the motor parameters
Diagnosis
Maximum continuous voltage level (15s)
410
815
970
1175
