Boumatic TouchPoint Installationsanweisungen Seite 15

TouchPoint™ und SmartControl™-Messgerät
Installationsanweisungen
Tabelle 2: Stecker am TouchPoint
Nr. Bezeichnung Beschreibung
1 J1, Pin 1
J1, Pin 2
J1, Pin 3
J1, Pin 4
2 J2, Pin 1
J2, Pin 2
J2, Pin 3
J2, Pin 4
J2, Pin 5
J2, Pin 6
3 J3, Pin 1
J3, Pin 2
J3, Pin 3
J3, Pin 4
J3, Pin 5
4 J4, Pin 1
J4, Pin 2
J4, Pin 3
J4, Pin 4
J4, Pin 5
J4, Pin 6
J4, Pin 7
J4, Pin 8
5 J5, Pin 1
J5, Pin 2
J5, Pin 3
J5, Pin 4
6 J6, Pin 1
J6, Pin 2
J6, Pin 3
J6, Pin 4
7 J7, Pin 1
J7, Pin 2
J7, Pin 3
J7, Pin 4
J7, Pin 5
J7, Pin 6
8 J8
DC Common
DC Common
+24 V GS
+24 V GS
PRISM-Hauptschirm
PRISM-Hauptschirm (Main)
PRISM-Main „A"
PRISM-Main „A"
PRISM-Main „B"
PRISM-Main „B"
PRISM-Nebenschirm (Sub)
PRISM-Sub „A"
PRISM-Sub „B"
DC Common
+24 V GS
DC Common
AUX-Eingang 1
DC Common
AUX-Eingang 2
DC Common
AUX-Eingang 3
QuickStart-Eingang
+24 V GS
AUX-Ausgang 1
+24 V GS
AUX-Ausgang 2
+24 V GS
AUX-Ausgang 3
+24 V GS
AUX-Ausgang 4
+24 V GS
AUX-Ausgang 5
+24A V GS
AUX-Ausgang 6
+24A V GS
+24A V GS
+24 V GS
Programmierung
15 9g925
2/21/13
