5 Using the robotic mower in a team
► Transfer information to the mowing area:
– Outline of the mowing area
– Position of the docking stations
– Routing of the perimeter wire
– Routing of the guide wires
Preparing mowing areas
► Remove any objects lying around.
► Remove metals, magnetic materials and mate‐
rials that conduct electricity as well as old
perimeter wires.
► Mow lawns with a lawn mower to the cutting
height that will later be set for the operation of
the robot mower. The default setting for the
cutting height on the robot mower is a = 6 cm.
► Level out holes and rough, uneven patches.
Using a wire installation machine
NOTICE
■ It is recommended that the wires be installed
with a wire installation machine so that the
guide wires and perimeter wire are not dam‐
aged. This protects the wires during lawn care
(e.g. aeration) and match operations.
► Do not work with machines that penetrate
the soil deeper than the guide wires and the
perimeter wire that have been installed.
► Maximum depth for installing the guide
wires and perimeter wire: a = 10 cm.
5.2.2
Preparing the robotic mower for opera‐
tion
► Remove the packaging material and transport
locks.
► Ensure that the following components are in a
safe condition:
0458-036-9801-A
– Robotic mower,
– Mowing unit,
– Battery,
– Docking station and power supply,
► Positioning the docking station,
► Installing the guide wire,
► Installing the perimeter wire,
► Electrically connecting the docking station,
5.6
a
► Setting up the team,
► Locking the Bluetooth
► If you cannot carry out these steps: Do not use
the robotic mower and contact a STIHL
authorized dealer instead.
5.3
5.3.1
A
a
1
► Choose the location for the docking stations
so that the following conditions are met:
– The docking stations are on the mowing
– There are no obstacles along the routing of
– The charging cables (1) can be installed
– The docking stations and power supplies
– If possible, protect the location against
– If possible, the docking stations are within
4.6.1
4.6.2
4.6.3
®
Positioning the docking station
General requirements
B
1
area (A), directly adjacent to the mowing
area (B) or outside of the mowing area (C).
the guide wires.
outside of the mowing area to connect to a
suitable wall socket.
are positioned in a clearly visible area.
adverse weather conditions and direct sun‐
light.
range of a wireless network (WLAN connec‐
tion).
English
4.6.4
5.3
5.4
5.5
5.7
radio interface,
7
C
1
