1756-Ig16; Controllogix-Ttl-Eingangsmodul - Allen-Bradley Digitale ControlLogix-E/A-Module Benutzerhandbuch

Kapitel 8 Verdrahtungspläne
Standardverdrahtung
– DC
IN-1
IN-3
5V DC
IN-5
IN-7
+ DC
DC-0(+)
IN-9
IN-11
IN-13
IN-15
DC-1(+)
Vereinfachtes Schaltbild
+5 DC
1.5 K
1 K
IN
1.5 K
1 K
IN
DC COM
140

1756-IG16

ControlLogix-TTL-Eingangsmodul

1756-IG16
2 1
IN-0
4 3
IN-2
6 5
IN-4
8 7
IN-6
10 9
DC COM 0
12 11
IN-8
14 13
IN-10
16 15
IN-12
18 17
IN-14
20 19
DC COM 1
74HCT14
560
74HCT14
560
Rockwell Automation-Publikation 1756-UM058H-DE-P – Mai 2015
CE-konforme Verdrahtung
1756-IG16
2
IN-1
4
IN-3
6
IN-5
8
IN-7
+
DC Power Wire
10
– DC-0(+)
12
IN-9
14
IN-11
16
5V DC Power
IN-13
18
IN-15
20
DC-1(+)
I/O Wire
1
IN-0
3
IN-2
5
IN-4
I/O Wire
7
IN-6
9
DC COM 0
11
IN-8
13
IN-10
Capacitor
15
0.01 μ F Typical
IN-12
(See notes below.)
17
IN-14
19
DC COM 1
+
–
TTL Input
Device
