1756-Ib16D; Controllogix-Dc-Diagnose-Eingangsmodul (10-30 V) - Allen-Bradley Digitale ControlLogix-E/A-Module Benutzerhandbuch

Kapitel 8 Verdrahtungspläne
Vereinfachtes Schaltbild
IN-0
GND-0
136

1756-IB16D

ControlLogix-DC-Diagnose-Eingangsmodul (10–30 V)
ControlLogix-
Eingang +5 V
Backplane-
Schnittstelle
Anzeige
GND
Drahtbruch
Empfohlene Ableitwiderstandgröße 1/4 W, 5 %
3,9 K
5,6 K
15 K
20K
Rockwell Automation-Publikation 1756-UM058H-DE-P – Mai 2015
1756-IB16D
Daisy Chain to Other RTBs
GND-0 2 1 IN-0
GND-0 IN-1
4 3
Group 0
GND-0 IN-2
6 5
GND-0 IN-3
8 7
GND-1 10 9 IN-4
GND-1 IN-5
12 11
Group 1
GND-1 IN-6
14 13
GND-1 IN-7
16 15
GND-2 IN-8
18 17
GND-2 IN-9
20 19
Group 2
GND-2 IN-10
22 21
GND-2 IN-11
24 23
GND-3 IN-12
26 25
GND-3 IN-13
28 27
Group 3
GND-3 IN-14
30 29
GND-3 IN-15
32 31
GND-3 Not Used
34 33
Not Used Not Used
36 35
– +
DC COM
Netzspannung
10 V DC
12 V DC
24 V DC
30 V DC
Group 0
Leakage Resistor
Group 1
Group 2
Leakage Resistor
Group 3
