6. Commissioning, operation

6. Commissioning, operation

6.1 Commissioning

6.1.1 Instrument overview

12
11
10
9
6.1.2
OUT electrical/temperature modules
1
IN electrical/temperature modules
2
DC 24 V pover supply
3
Environmental parameter connector
4
Home function
5
Programmable function
6
Connectors for external P sensor
7
Changing the number of windows
8
Power OFF
9
Power ON
10
Connector for battery charger
11
RS-232 interface
12
