6. Commissioning, operation

6.7 Data logger

Options are available on the screen for the functions setting (see chapter 6.5.2 "Scaling"):
EN
On the LOGGER column, the following options are available:
Option
LIST
SETUP
DELETE ALL
With this function you can configure the data logger for all 4 channels simultaneously.
Selecting SETUP, "Data Logger Setup" will be displayed as per below:
Option
Log Name
Sampling time
Sampling length
Pressing [START], the logging process will start:
66
Fig. 82 - Logger screen
Meaning
Setup of the logger
View log data
Delete all the logs
Meaning
Name of the log (compulsory)
Sampling time between 2 measurements (hours, min., sec.)
Total time of the logging
Fig. 83 - Logger data setup
