6. Commissioning, operation
Pressing [POINTS], the list of the calibration points will be shown:
EN
Pressing [RESULT], the calibration results are shown:
The buttons on the bottom of the screens allow to access further points (if present): As found, As left, Up, Down will appear
to enable to see the calibration results related to the different calibration stages.
Function
As found
As left
Up
Down
On the screen for the functions setting (see chapter 6.5.2 "Scaling") press [DELETE ALL] to delete all the reports in the
memory.
A confirmation message will appear before deleting all data
60
Fig. 80 - Display test points report
Fig. 81 - Display report results
Meaning
Calibration points before any adjustment on the DUT
Calibration points after the adjustment on the DUT has been carried out
Calibration points going up
Calibration points going down
WIKA operating instructions, model Pascal ET
