4. Design and function
Compensation instrument (up to 4 in-out signals)
■
Electronic and pneumatic receiver
■
Electronic and pneumatic controller
■
Electronic and pneumatic recorder
■
Miscellaneous instrument
■
Pascal ET includes different modules and can be ordered with different hardware configurations.
The hardware configuration depends on the installation of different functional modules:
Two electrical/temperature IN modules (IN A and IN B)
■
Two electrical/temperature OUT modules (OUT A and OUT B)
■
One pressure module able to support up to two sensor (2 internal, 2 external or a combination of both)
■
One environment parameters module (atmospheric pressure, ambient temperature and relative humidity)
■
One power supply DC 24 V
■
One RS-232 interface
■
One connection for recharging the battery
■
Battery life
In order to preserve battery life is recommended to keep the battery charger connected for no more than 36 hours
Functional module
A functional module is a hardware component that allows the Pascal ET to perform some operations like for
example measurement and generation of electrical signals and pressure.

4.2 Scope of delivery

Portable multi-function calibrator model Pascal ET
■
Operating instructions
■
AC adapter
■
Pascal report software
■
RS-232 interface cable
■
RS-232 to USB adapter
■
Electrical kit order no. 241076
■
Pneumatic pressure kit (depending on pressure range)
■
3.1 calibration certificate per DIN EN 10204
■
Cross-check scope of delivery with delivery note.

4.3 Power supply

Charging
To avoid false measurements, charge the rechargeable batteries as soon as the battery indicator appears. If the batteries run
too low, the Pascal ET will automatically shut down.
Use only the original AC/DC converter which is supplied by WIKA
