6. Commissioning, operation
During the configuration process the operator can name the report: the same can be recalled when the same procedure is
required.
In any moment the operator can stop the calibration pressing [ABORT].
EN
To make the zero on the reference channel REF, press [OFFSET ON] before storing the first calibration point: this function is
displayed as OFS on the channel display, under the measurement value.
Press again [OFFSET ON] to come back to the original configuration: OFS will disappear.
Once the last calibration point is done, press [STORE] (or [ABORT]): the report will end automatically and the display will go
back to its original configuration.
On the screen for the functions setting (see chapter 6.5.2 "Scaling") press [LIST] to view the stored reports:
Fig. 78 - Display report list
The previou picture shows the list of the existing report: name and status are displayed.
Under the status, the writing AS FOUND is displayed when the calibration data refers to a calibration process done on an
instrument without any adjustment: when a date is available this means that calibration process is complete (AS FOUND AS
LEFT). If the report has never been run, VOID will be displayed next to the name.
Press the arrows to move the cursor up and down to select the report, press the button with light grey background to visualize
the information available in the report.
To cancel the reports press and keep pressed the button with light grey background: a confirmation is required by the operator
before proceeding.
Selecting the area with light grey background next to the report name, the [SETUP] of the report will be displayed:
Fig. 79 - Display report setup
