6. Commissioning, operation
Some dry-well calibrators require the interface converter kit.
Function
Stabil. wait time
Stabilization time
Stabilization band
Stabilization band
The value describes above depend of the type of the connected dry-well calibrator and its setting specifications.
Consider the following chart:
Stab. Wait time
Set new temperature
WIKA operating instructions, model Pascal ET
Meaning
Set the stability waiting time in the hh:mm:ss format.
The Pascal calibrator, after setting the temperature point for the report for the serial interface, will wait this
dead time before starting to detect the temperature stability value.
The algorithm for detecting the stability value will consider the temperature stable by using the two set
parameters. When the instrument will detect a stable temperature, the report will store the values of the
thermometers and then will proceed to the next set point.
The parameter indicates the temperature range where the temperature value must not fall within for the set
time. This allows to detect a stable temperature value.
X Axis
Stabilization reached
Stab. time
Time
